With an all-new look, the Force Master 2.1 control unit is much easier to configure. Making products more ergonomic and easy to use has always been a Malossi goal: Force Master 2.1 is a contemporary, adequate and super performing product. With an interface for the K and CAN communication lines, a new user interface and the addition of a capacitive ignition input, Force Master 2.1 is the ideal complement for vehicle performance management: without functional limitations, it allows the engine to be pushed beyond the barrier of the original rev limiter. Technical details Carburation adjusting ±…

With an all-new look, the Force Master 2.1 control unit is much easier to configure. Making products more ergonomic and easy to use has always been a Malossi goal: Force Master 2.1 is a contemporary, adequate and super performing product. With an interface for the K and CAN communication lines, a new user interface and the addition of a capacitive ignition input, Force Master 2.1 is the ideal complement for vehicle performance management: without functional limitations, it allows the engine to be pushed beyond the barrier of the original rev limiter. Technical details Carburation adjusting ±…

Besides its improved fuel curves, efforts from Malossi’s technical staff resulted with a rev limiter increase of 1.200 RPM depending on the vehicle, making Force Master an even higher performing ECU! Force Master allows to change the injection in order to fit perfectly the Malossi 4-stroke and original cylinders. Carburation adjusting ± 20% at min/medium/max RPM limiter : + 1.200 RPM Original 9.800 - Malossi 11.000 4 different maps : curve 0 : original exhaust system, original cylinder, original head, original camshaft and original filter curve 1 : original exhaust system, Malossi cylinder,…

Malossi is proud to offer its new Digitronic ECU with variable ignition timing! Compared to the original ECU, Malossi has completely modified the ignition timing performance maps and increased the rev limit to 15,000 RPMs. The new Digitronic controls the ignition timing and SAS valve. Ignition Timing Performance Map The ignition timing is controlled by performing a linear interpolation of a tri-dimensional performance map, containing 16 break points for engine speed and 8 break points for engine temperature. SAS Valve Performance Map The secondary air supply to the base of the throttle body…

MHR Team II ignition is a great innovation!!! Manages multiple maps simultaneously without having to resort to a hand-held device, with just a simple click. Ability to shift the selected map by moving the OFFSET (± 2°). The inner rotor ignition systems designed by Malossi are based on the state-of-the-art technology applied to racing. Such a new system resulted from the need to overcome the technical limitations imposed by conventional flywheel ignition, which cannot ensure consistent performance over 10,000 rpm and causes severe setting-up problems for racing vehicles. We made the control…

LIMITLESS Have you heard of the theory that argues we use only twenty per cent of our brain? With Force Master 3 you'll use a hundred per cent... of your engine! To improve our most advance control module, we designed with vision, starting with the milestones achieved so far. Thus was conceived Force Master 3, a futuristic control module both in hardware and in software. INTEGRATED LAMBDA EMULATOR The original control module of the scooter, for analysis of the air/fuel ratio and to adjust the carburetion accordingly, normally interfaces with the lambda sensor installed on the silencer. force…

STROBE CONTROLLER The perfect accessory for our new MHR TEAM II Malossi inner rotor ignitions. This compact tool not only allows the advance to be checked with disarming ease, thanks to a 200 lm light with a duration of 10 µs and extremely reduced delay (<1µs), it also completely replaces classic strobe guns thanks to its technical characteristics, decidedly superior to many guns currently available on the market. To activate the controller, the cables simply need to be connected to the battery and ignition coil. Once map 0 has been set in the MHR TEAM II Malossi , inner rotor ignitions,…

HEAT MASTER Sorgt dafür, dass Ihr Motor einen kühlen Kopf behält. Die Steuerung der Betriebstemperatur eines Motors ist von grundlegender Bedeutung. Es genügt nicht nur zu wissen mit wie vielen Graden ein Antrieb arbeitet, sondern die Temperatur muss auch entsprechend der verschiedenen Betriebsbedingungen variierbar sein. Malossi hat diese Notwendigkeit erkannt und hat den HEAT MASTER entwickelt, ein elektronisches Steuersystem zur Ergänzung der ENERGY PUMP , das in der Lage ist, die Motortemperatur in Echtzeit zu steuern. Der HEAT MASTER kann an vielen verschiedenen Rollertypen und an…

Besides its improved fuel curves, efforts from Malossi’s technical staff resulted with a rev limiter increase depending on the vehicle, making Force Master an even higher performing ECU! Force Master allows to change the injection in order to fit perfectly the Malossi 4-stroke and original cylinders. Carburation adjusting ± 20% at min/medium/max RPM limiter : Original 9.300 - Malossi 9.300 (*) 4 different maps : curve 0 : Malossi exhaust system with db killer, original cylinder, original head, original camshaft and original filter curve 1 : original exhaust system, Malossi cylinder, original…
