Technical features Cylinder Bore: Ø 63 mm Stroke: 58.7 mm Displacement: 183 cc Compression ratio: 11.27 Material: primary aluminium alloy with a high content of hardened and tempered silicon, cylinder liner with silicon carbide coating in a galvanic nickel die and crossed smoothing with two diamond passages with very limited tolerances. Machining: on machine tools with high precision numerical control. Cylinder-piston connection with an allowance of 0.05 mm. Recalculated and upgraded heat exchange surfaces. Piston Ultra compact with 3 rings. Material: special aluminium alloy with high silicon…

Cylinder Material: special self-lubricating, wear-resistant, highly refined cast iron alloys, obtained by Shell Moulding gravity die-casting. Machining: on numerically controlled high precision machine tools. Recalculated and increased heat exchange surfaces. Exhaust and transfer ports designed and tuned for maximum thermodynamic performance. Dimensional and surface finish quality control performed according to Malossi's internal specifications. Cylinder and piston selected for a 100% fit of 0.010-0.005 mm. Checking of all the seals carried out. Piston Material: special aluminium alloy with…

Malossi mit der Sachkenntnis und der Fähigkeit, umfassende Erfahrung mit der neuesten Technologie zu verbinden, nahm diese Herausforderung an: Einen Zweitaktmotor mit Benzineinspritzug auf die Rennstrecke zu bringen. Mit dem neuen Produkt-Linie INJECTION TECH wurde ein neues Kapitel geschrieben, eine Antwort, die von der Rennszen erwartet wurde, um den Anprüchen bei der wachsenden Zahl von Malossi Trophy Rennen für 70cc Scooter gerecht zu werden. Technische daten Zylinder aus Gusseisen -- Technologie Material: Spezielle selbstschmierende Gusseisenlegierung, verschleißfest und hoher…

Technische Daten Material: alluminium Kühlung: flüss Bohrung: 47 mm Hub: 37,8 mm Hubraum: 65 Kompression Sverhältnis: 13:01 Verteilung: 6 Kanäle

The Malossi 180 H2O cylinder kit was born from years of direct development in competition, on the same scooters for which it was originally designed, the Gilera Runner . It's the component for you if you want to convert a 125cc liquid-cooled 2-stroke engine into a 180cc one. Reliable and robust, it ensures effective thermal dissipation even under prolonged stress, keeping the engine at constant temperature and performance over time. The geometry of the head – completely redesigned with a truncated cone dome with a central spark plug, an enlarged exhaust duct, and a third transfer port open at…

Technische Daten Material: alluminium Kühlung: flüss Bohrung: 45,5 mm Hub: 39,1 mm Hubraum: 65 Kompression Sverhältnis: 12,9:1 Verteilung: 6 Kanäle

Spaß ohne Komplikationen (6 Überströmer - 2 Kolbenringe) Die Zylinderkits aus Gusseisen von Malossi sind der erste und einfachste Schritt, um ihren Motor zu verändern; sie stellen eine optimale Lösung dar, um weiterhin eine serienmäßige oder genehmigte Auspuffanlage zu verwenden. Dies ist der erste und einfachste Schritt, um ihren Motor zu verändern. Bei diesen Zylinderkits kombiniert sich die längere Lebensdauer des Gusseisens mit den fast schon übertriebenen Qualitätsstandards von Malossi. Malossi ist einer der wenigen Unternehmen, die auch Höchstleistungen von dieser Klasse an Zylinderkits…

Technical features Cylinder Material: alluminium Cooling: liquid Bore: Ø 67 mm Stroke: 47,2 mm Capacity: 166,4 Compression ratio: 1:11,4 Material: primary aluminium alloy with a high content of hardened and tempered silicon, cylinder liner with silicon carbide coating in a galvanic nickel die and crossed smoothing with two diamond passages with very limited tolerances. Machining: on machine tools with high precision numerical control. Cylinder-piston connection with an allowance of 0.05 mm. Recalculated and upgraded heat exchange surfaces. Piston Ultra compact with 3 rings. Material: special…

After much success with Piaggio crankcases, Malossi completes the task: Aluminium Ø47 BIG D.E.P.S. Cylinder and Head Kits are now available again! The only CIAO/SI cylinders on the market with a split exhaust port and symmetrical transfer ports!!!! Threaded type exhaust header offers two major advantages: Increased strength and the possibility for replacement due to failure Possibility to increase the exhaust size hence increasing the performance These results are possible due to a smaller decompression valve, compared to the Piaggio original, which is supplied with the kit. Centred,…

Force Master is the innovative CDI which allows to change the injection in order to fit perfectly the Malossi 4-stroke cylinder kit. This CDI has been scheduled with different maps so as to be coupled perfectly with your vehicle whatever its setting is! Complete cylinder I-TECH 4 STROKE Material: primary aluminium alloy with a high content of hardened and tempered silicon, cylinder liner with silicon carbide coating in a galvanic nickel die and crossed smoothing with two diamond passages with very limited tolerances. Machining: on machine tools with high precision numerical control.…

CVF2 ZYLINDER TECHNISCHE DATEN ZYLINDER AUS ALUMINIUM Hergestellt durch Schwerkraftfusion in speziellen Stahlformen. Material: Primäre Aluminiumlegierung mit hohem Siliziumanteil, vergütet und stabilisiert. Bearbeitung auf rechnergesteuerten Präzisionsmaschinen. Büchse mit Einsatz aus Siliziumkarbit in einer Matrize aus galvanisiertem und kreuzgeschliffenem Nickel mit Diamantschliff mit engen Toleranzen. Neu berechneten und vergrößerten Wärmeaustauschflächen. Abgas- und Abfülleitungen für eine maximale thermodynamische Leistung entworfen und getestet. Dimensionskontrolle der Form und Rauheit…

CYLINDER KIT Ø 63 ALUMINIUM completely new cylinder kit has been created, designed overall to obtain the maximum result in terms of performance and durability. Every aspect of the system has been studied to maximise the mechanical resistance, the fluid dynamics and improve combustion: the result is a top-of-the-range kit in terms of construction quality and technological development. TECHNICAL FEATURES Cylinder Built from scratch, in high-strength aluminium alloy and cylinder sleeve with nickel-chromium coating. Consisting of an even thickness central core around the cylinder sleeve and the…

VESPA NEVER DIES Aluminium cylinder kit Ø 68,5 Afurther upgrade for the timeless Ø 68.5 cylinder kit! 1983 The aluminium cylinder with 68,5 mm diameter - turning point in Vespa tuning - was born. Made of Nicasil aluminium, with super light piston and 1.2 mm semi trapezoidal rings, it becomes a legend, a real musthave for all Vespa fans. 2008 The cylinder is updated, by adding the head with hemispherical combustion chamber and central spark plug. 2013 The cylinder, always made of Nicasil aluminium, has been completely changed concerning both main and rear ports and exhaust port as well.…
