"OVER RANGE" Malossi transmission system This new transmission system takes full advantage of the Malossi components already on sale last year, by adding several new parts that make the entire system particularly suited to the enormous power available. This latest system hinges on the new Fixed Pulley of the torque driver that has a larger diameter and the very latest specifications. The larger diameter of this pulley allows one to have a greater velocity-ratio range compared to the original pulley that has a notably smaller external diameter. Malossi engineers have also taken particular care…

Torque Driver Malossi Aluminium Rear Pulley System MHR Aluminum, now in aluminium for lightness and strength increase. The pulley is riveted to the hubs for maximum strength and to reduce the tolerance between the hub and the bushing. The surface roughness is just Ra 0.4.

New fixed half-pulley for Yamaha T Max 530! Larger external diameter (186 mm, +3 mm compared to the original one), redesigned working angle (13°) and diamond finish of the belt-side pulley surface to further increase the gearing range! This component completes the Multivar and renders it unparalleled! Suitable even to original variator. Note : In the event that the Ventilvar is coupled with the MULTIVAR 2000 MHR ABSOLUTELY DO NOT USE the spacer supplied with the variator kit, this would create interference between the belt and engine case.

Malossi Super T Max quickens its steps. Mhr Power Transmission, art. 6714757, is a Malossi project: HTQ Z 26/40 pinion and ring gear pair with lengthened gear ratio, Malossi Morse lightened, narrower, frictionless racing chain. This system completely replaces the original primary gears (25-tooth pinion and 41-tooth ring gear) with a 26-tooth drive pinion and a 40-tooth driven ring gear, thus providing a 7% longer ratio. Besides providing this longer ratio, these gears are narrower, as to fit the new Malossi Morse racing chain, which is frictionless and without friction springs, thus lighter,…

MALOSSI K-DRIVE Malossi K-DRIVE is a lighter gear ratio than the original for the Yamaha Tmax 530 and Kymco AK 550. Characterised by a sought-after appearance, the K-DRIVE crowns and pinions have different ratios to satisfy all the rider’s requirements. Pinion 6117983B Z 24 6117984B Z 27 6117986B Z 28 6117985B Z 29 Crown 6117988B Z 56 6117982B Z 57 6117987B Z 58

"OVER RANGE" Malossi transmission system This new transmission system takes full advantage of the Malossi components already on sale last year, by adding several new parts that make the entire system particularly suited to the enormous power available. This latest system hinges on the new Fixed Pulley of the torque driver that has a larger diameter and the very latest specifications. The larger diameter of this pulley allows one to have a greater velocity-ratio range compared to the original pulley that has a notably smaller external diameter. Malossi engineers have also taken particular care…
